FEP is a melt processable copolymer of hexafluoropropylene and tetrafluoroethylene with superior electrical properties, excellent chemical resistance, and operating temperatures up to 200°C (392°F). Typical applications include high-temperature wire and cable insulation or jacketing, insulation for plenum-rated data cables, cast film, and tubing and injection molded parts for high temperature harsh chemical environments. (See also FEP Foam Products below)

FRL FEP is UL recognized (QMTM2 type – file E346136) for use at 100% in wire and cable insulation and jacketing.

FEP

Product Codes: 02.001.09.00 (clear), 02.101.09.00 (colors)

FRL Grade Applications MFR Range Downloads
HM Wire and cable, tubing, and film for extreme thermal, mechanical, and chemical environments. 2-5 Data Sheet
MM Wire and cable, tubing, and film for extreme thermal, mechanical, and chemical environments. 6-9 Data Sheet
MMU Wire and cable jacketing, films, tubing, injection molding 10-13 Data Sheet
MMUPLUS Wire and cable jacketing, films, tubing, injection molding 14-21 Data Sheet
LML Injection molding; thin-walled wire and cable or tube extrusion 22-25 Data Sheet
LMLPLUS Injection molding; thin-walled wire and cable or tube extrusion 26-27 Data Sheet
LM Higher speed extrusion of wire and cable jackets, tubing, or film. 28-32 Data Sheet
LMPLUS Higher speed extrusion of wire and cable jackets, tubing, or film. > 33 Data Sheet



FEP for Data Communication Cables

Product Codes: 03.111.18.00 (insulation), 03.111.19.00 (filler)

FRL Grade Applications MFR Range Download
LMLX Datacom cable insulation and filler 22-25 Data Sheet
LMX Datacom cable insulation and filler 28-32 Data Sheet



FEP Foam

Product Codes: 02.027.09.00 (white), 02.127.09.00 (colored)

Our products also include various grades of foamable FEP for specific applications. A variety of melt flow ranges are available; please contact us for details.
